Yaylı Rondela
Ürün Adı: Yaylı Rondela
Ürün Kodu: UNC & UNF
Thread size / Anma çapı |
1/8 |
5/32 |
3/16 |
1/4 |
5/16 |
3/8 |
7/16 |
1/2 |
9/16 |
5/8 |
3/4 |
7/8 |
1" |
1 1/8 |
1 1/4 |
1 1/2 |
1 5/8 |
1 3/4 |
2" |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hole dia / Delik çapı | d1 | 3.6 | 4.1 | 5.1 | 6.5 | 8.1 | 10.2 | 11.3 | 13.0 | 14.2 | 16.2 | 20.2 | 22.5 | 26.5 | 30.5 | 32.5 | 39.5 | 42.5 | 45.5 | 51.0 |
| +/- | 0.3 | 0.3 | 0.3 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 | 0.8 | 1.0 | 1.0 | 1.0 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.5 | |
| Outside dia / Dış çap | d2 | 6.7 | 7.6 | 9.2 | 12.2 | 14.8 | 18.1 | 19.2 | 21.9 | 24.1 | 27.4 | 33.6 | 35.9 | 42.0 | 48.2 | 50.2 | 61.2 | 68.2 | 71.2 | 77.0 |
| Thickness / Et kalınlığı | s | 0.8 | 0.9 | 1.2 | 1.6 | 2.0 | 2.2 | 2.2 | 2.5 | 3.0 | 3.5 | 4.0 | 4.0 | 5.0 | 6.0 | 6.0 | 6.0 | 7.0 | 7.0 | 7.0 |
| Height / Yükseklik | h | 1.8 | 2.1 | 2.8 | 3.8 | 4.7 | 5.2 | 5.2 | 5.9 | 7.1 | 8.3 | 9.4 | 9.4 | 11.8 | 14.2 | 14.2 | 14.2 | 16.5 | 16.5 | 16.5 |
| Width / Genişlik | b | 1.3 | 1.5 | 1.8 | 2.5 | 3.0 | 3.5 | 3.5 | 4.0 | 4.5 | 5.0 | 6.0 | 6.0 | 7.0 | 8.0 | 8.0 | 10.0 | 12.0 | 12.0 | 12.0 |
| Weight / Ağırlık | gr/p | 0.12 | 0.18 | 0.36 | 0.93 | 1.60 | 2.53 | 3.00 | 3.95 | 6.01 | 8.91 | 15.2 | 16.5 | 27.5 | 44.3 | 44.3 | 71.7 | 111 | 117 | 152 |
